Brief Introduction

REL-MR-12DC/21-21AU

Product type: Single relay, miniature power relay with plug-in connection with multi-layer gold-plated contacts.Electrical characteristicsInput data: The input voltage is rated at 12V DC and the input voltage range is from 7.8V DC to 29.76V DC. The drive is monostable and non-polarized, with a typical input current of 33mA, a typical response time of 7ms, a typical release time of 3ms, a coil resistance of 360Ω±10% at 20°C, and a maximum power consumption of 0.4W at rated input voltage.
